Product Description
Road crack cut and grooving machine primarily shared with the road sealing machine so as to widen the cracks in concrete pavement or asphalt pavement, in this way, you can repair the road cracks. This device adopted the U.S. Kohler 25 hp gasoline engine, equipped with triple heavy-duty air filter, reliable, stable performance, suitable for harsh environments.
Advantage
1.Easy and safe operation. Quick stop system emergency brake switch effectively protect operators. Press the stop switch, the engine shut down, and the cutter stops turning in 4 seconds.
2.High efficiency. Fast slotting speed and strong practicability.
3.Good dust absorption effect. Keeping the working environment clean, in favour of the operators health and environmental protection.
4.Cutting head is adopted for stepless speed regulation.
5.Good dust resistance. Extends the life of air filters and engines.
6.High quality maintenance-free battery. Longer life, more convenient, more durable and faster.
7.Controllable height and depth. Electric push rod is used to adjust the height of slotting cutter, and the depth indicator enables the construction personnel to control the groove depth according to real condition.
8.Avoid wrong operation. To ensure falling blade accuracy, crack tracking indicator needle makes slotting machine follow the crack accurately.
9.Good quality. National standard high thickness steel shell, it’s not easy to damage.
Application
Road crack grooving machine is mainly used for widen crack before amending seam in asphalt surface.
In addition, it has other powerful functions. It can be used for the construction of cement pavement, concrete road surface and even ice surface
Technical Parameter
Model | TDK-300 | TDC300 | |
Cutting width | 8-50mm | 12-20mm | |
Cutting depth | 0-50mm | ||
Engine | Honda GX690 | ||
Engine power | 11KW | 18KW | |
Safety braking system | Adopt electronic safety control system | ||
Dust suction system | Effective dust absorption can be achieved | ||
Fuel Capacity | 24L | 18L | |
Blade quantity | 6 | ||
Machine weight | 260KG | ||
Boundary dimension | 1830X900X1000mm | 900X780X1480mm | |
Accumulator | 12V 45Ah | ||
Cutterhead | External diameter | 122mm | |
Inner diameter | 25mm | ||
Slot width | 12mm | ||
Total width | 23mm | ||
